Single Bag Filter Housing

Description

Single bag filter housing with one filter bag has the simplest structure and easy to operate. Widely applied in high precision filtration with small treatment capacity requirement. It is suitable for pre-filtration, end-filtration, or a polishing filter for liquids with low solids concentration.

Our company single bag filter housing has a unique design that can effectively prevent the filter bag from falling into the filter basket under working pressure to ensure 100% no leakage. A magnetic rod can be installed in the equipment for Iron material filtration.

Working Principle

The pressure in the single-bag filter channel presses or draws the liquid into the filter cylinder. The liquid is filtered by the filter bag supported by the filter basket, resulting in solid-liquid separation. The filter bag can be reused or replaced.

Technical Data

Inlet/outlet type: Side-in & bottom-out, Side-in & side-out, Top-in & bottom-out
Filter precision: 0.5~500μm optional.
Treatment capacity: 10 ~ 45m3 / h
Construction material: Carbon steel, SS304,316, SS316L, Duplex 2205, 2507etc. (Insulation can be fitted with jackets)
Design pressure: 0.1~2.5 Mpa
Design temperature: 5 ° C ~ 120 ° C
Design standard: ASME, GB150 or HG/T21637-1991
Sealed type: O-ring and flat pad
Sealed material: nitrile rubber, silica gel, fluororubber
Interface form: thread, clamp, flange
Filter bag material: PP, PE, nylon, polytetrafluoro, stainless steel, etc.
Filter bag model: 1＃, 2＃，3#，4#
Connection nozzle: 1-1/2”
Drain: 1/4"
Surface treatment: Painting, mirror polishing, electrolysis polishing

Advantages

Better sealing effect to prevent side leakage.
Large effective filtration area and higher filtration efficiency.
It is more convenient and quicker to replace the filter bag, and the operation cost is lower.
Reasonable structure, more stable and reliable filtration.
The installation height is adjustable to meet the space requirements of specific applications.
